Wholesale Utility ATV

MFB-400-C Utility

Gas 500cc ATV	Displacement 500cc
Starting from : $000.00

Back to ATV 110cc 125cc 150cc 200cc 250cc 350cc+

Call to order : 718-766-5432

SPECIFICATIONS
Engine - Drive Train
Engine Type	359.1cc 4-stroke, single cylinder
Carburation	Y
Max power	16.1hp - 5200rpm
Cooling System	Air Cool + Oil Cool
Transmission	5 Speed + reverse
Driveline	shaft, selectable 4*4, front limited slip differential
Starting System	Electric
Ignition	DCDI
Max Speed	50 Miles h
Max Torque	23n.m - 4000rpm
Battery	12V - 14Ah
Steering	Rack and pinion
Brakes - Suspension - Chassis
Frame	Steel Frame and Body
Front Suspension	Independent double wishbone
Rear Suspension	Independent double wishbone
Front Brakes	Disc Brake
Rear Brakes	Disc Brake
Brake Operation	Hand - Foot Brake
Front Tires	25×8-12
Rear Tires	25×10-12
Clutch	Automatic
Engine oil	SAE15W 40SF
Gear oil	85W - 40
Fuel Capacity	3.5 gallons
Controls - Safety
Age Recommendation	10 Years old and above
Thumb Throttle (Y-N)	Y
Brake Pedal (Y-N)	Y
Remote Start (Y-N)	Y
Remote Engine stop (Y-N)	N
Kill Switch(Y-N)	N
Speed Governor (Y-N)	N
Light	Head lights, Signal lights, Tail lights.
Capacities - Dimensions
Weight Capacity	600 LBS
Net Weight	603.LBS
Gross Weight	670 LBS
Length	82.7"
Width	47.6"
Height	47.2"
Ground Clearance	11"
